LED Energy Saving Tri-Proof Light with 10W 18W 26W 36W 54W

Color Temperature:

Nature White

Tube Type:

T8

Shade Material:/dt>

PC

1FT/2FT/3FT/4FT/5FT LED Energy Saving Tri-Proof Light with 10W/18W/26W/36W/54W

Basic Info.

Model NO.:

led batten

Lamp Holder/base:

Full Range

LED Type:

SMD 2835

Shell Type:

Frosted

Lifespan:

30000H

Warranty:

2 Years

Certification:

CE, RoHS, C-tick, NOM, EMC, LVD

Input Voltage:

85-265V

LED Chips:

Epistar

Ra:

80

PF:

0.9

CCT:

3000K/4000K/6000K

Housing Material:

Aluminum Alloy + PC Cover

IP:

20

Lenghth:

0.3m, 0.6m, 0.9m, 1.2m, 1.5m

Chip Brand:

CREE, Epistar, Samsung

Mercury:

No

Beam Angle:

120 Deg

Energy Efficiency Label:

A Grade

Transport Package:

Color Box

Specification:

1FT/2FT/3FT/4FT/5FT

HS Code:

85395000

Production Capacity:

600000PCS/Month

LED Energy Saving Tri-Proof Light with 10W 18W 26W 36W 54W advantage:

1. only 50% energy consumption compared to fluorescent tube;

2. Lumen Efficiency can be up to 95LM/W;

3. Replace traditional T8/T12 medium bi-pin base fluorescent tube lighting;

4. Full PC, Alu+PC for options;

5. Retrofit to existing T8 lamps on EM ballast installations;

6. CRI >80 with good redering performance;

7. Long lifetime more than 30000H;

8. 2 years warranty;

9. No Mercury;

10.Widely used in public settings such as station, office, shipping mall,school

LED Energy Saving Tri-Proof Light with 10W 18W 26W 36W 54W Technical Specification

Model	Linear30	Linear60	Linear90	Linear120	Linear150
Wattage	10W	18W	26W	36W	54W
Incandescent Equivalent	18	36	58	68	100
Voltage	220-240v	220-240v	220-240v	220-240v	220-240v
Lumen Efficiency	95lm/w	95lm/w	95lm/w	95lm/w	95lm/w
PF	>0.9	>0.9	>0.9	>0.9	>0.9
CRI	80	80	80	80	80
Cap	G13	G13	G13	G13	G13
Beam Angle	270°	270°	270°	270°	270°
Working Temperature	-20°~40°	-20°~40°	-20°~40°	-20°~40°	-20°~40°
Daimeter	75mm	75mm	75mm	75mm	75mm
Length	300mm	600mm	900mm	1200mm	1500mm
Lifetime	30000H	30000H	30000H	50000H	50000H
Warranty	2 years	2 years	2 years	3 years	3 years

LED Energy Saving Tri-Proof Light with 10W 18W 26W 36W 54W Application:
