Lamp Body Material:Aluminum
Projection Distance:25-35m
Application:Park, Square, Factory, Garden, Tunnel
Outdoor 200W 250W 300W 400W 500W 600W LED Flood Light Industrial LED Light for Outdoor Square Building Landscape Tennis Court Lighting Basic Info.
Certification:
CE, EMC, LVD, RoHS, SAA, UL
Operating Voltage:
100-240V
Input Voltage:
AC100-277V, 50Hz~60Hz
LED Chips Brand:
Samsung
Delivery Time:
7-10 Days
Lifespan:
50000 Hours
Color Rendering Index:
Ra>80
Lumen Efficiency:
>140 Lm/W
Power Factor:
>0.98
Power Efficiency:
>92%
Lamp Driver:
Meanwell Lighting
LED Qty:
512PCS
Size:
598*283*130mm
Viewing Angle:
60/90/60*150 Degree
Transport Package:
1 Piece/Carton
Specification:
CE, RoHS, SAA
HS Code:
9405409000
Production Capacity:
40000PCS/Month
Specifications of 300W Flood Light LED,LED Flood Light Industrial LED Light for Outdoor Square Building Landscape:
| 300W LED Floodlight Main Technical Parameters | |||
| Item No.: | 300W | ||
| Input Voltage: | AC 100-277V | ||
| Freqency Range: | 50Hz~60Hz | ||
| Power Factor: | >0.98 | ||
| Power Efficiency: | >92% | ||
| Lamp Driver | Meanwell Driver | ||
| LED Chip: | 3030SMD | ||
| LED Power | 300W | ||
| LED QTY: | 384pcs | ||
| LED Working Voltage: | DC36 ~42V | ||
| System Consumption: | 310W | ||
| LED Luminous Flux | Warm White | 38000LM | |
| Pure White | 38900LM | ||
| Cool White | 39000LM | ||
| Viewing Angle: | 60/90/60*150° | ||
| Illuminance Uniformity: | >0.6 | ||
| Color Temperature | Warm White | 3000K~3500K | |
| Pure White | 5000K~5500K | ||
| Cool White | 6000K~6500K | ||
| Color Rendering Index | Ra>80 | ||
| Light Distribution: | LED points visible | ||
| Light Design: | LED+The secondary light distribution lens | ||
| LED Junction Temperature: | ≤115ºC | ||
| Working Temperature: | -45ºC~55ºC | ||
| IP Grade: | IP66 | ||
| Working Life-span: | 50000 H | ||
| Power Line: | 1.0 m three line | ||
| Connect Wire | Brown | L | |
| Blue | N | ||
| Yellow / Green | G | ||
| The color of the lamp shell | Black | ||
| Size: | 598*283*130mm | ||
LED Chip: Cree LED Chips which is the most famous Brand in chips field, high efficiency high lumuns and long lifespan, high quality.
Power Supply: LED flood lights are adopted Meanwell ETL approved driver, IP65 and high quality, it improved lights performance. Power efficiency ≥92.
Colour temperature: LED floodlight provide a range of colour temperatures from 3000, 4000 and 6000 Kelvin helping to enhance a building's exterior.
Optics: Optical assembly: hermetically sealed providing IP65. Great light uniformity: Thanks to the advance LED optical systems the fixture maximize the utilization of light onto the target area, improving the uniformity of light.
Housing: Finned aluminum housing electrostatically sprayed with a polyester powder paint finish, following anti-corrosion priming, and oven cured at 180oC.
Cable: silicon rubber cable for power input. Fasten with screw in the cable gland.
Warranty: 5 years. Do not attempt to take housing apart as this will ruin the seal and void all warranty.
Certification: DLC FCC CE RoHS approval.
Quality Control: Rigorous product testing includes high-low temperature tests, waterproof tests, shockproof tests, burn-in testing, tensile test, salt spray test and more to ensure long-term performance.
Angle Adjustable: Adjustable stainless steel mounting bracket allows you to direct light where you need it.
Features of Outdoor Flood light LED,LED Flood Light Industrial LED Light for Outdoor Square Building Landscape:
1. High efficiency to meet rigorous photometric requirements.
2. System rating 50,000 hours LM80 to reduce maintenance.
3. LED Flood light has high-pressure cast aluminum electrical box painted electroplating both inside and outside, stainless steel or plating chromium fittings, making the installation flexible and convenient. Scuba patent technology making the optical system precision and efficiency.
4. LED high efficiency and long life, not only provides a bright, diversity, lasting and innovative lighting environment, but also greatly reduce the purchase system and maintenance costs.
5. Passed DesignLights Consortium (DLC) qualifications.
6. Vented housing design isolates LED module from driver for long life and improved performance.
7. Tempered glass lens protects LEDs and allows for easy cleaning/debris removal.
8. Adjustable mounting bracket allows you to direct light where you need it.
9. IP65 Rated.
Primary competitive advantages of our new design LED flood lights as below :
1. Taiwan MeanWell drivers, Samsung single power LED chips.
2. Finned radiators, very good heat dissipation.
3. Flexible positions can be adjusted within 180°.
4. Waterproof IP65 design,elimination mist,avoid condensation,widely used for indoor and outdoor environment.
5. Reflector 60° 90° 60*150° beam angles are available,meet the requirements of professional light distribution and can be use at different place.
6. 50W to 400W can be chosen, 5 years warranty.
Installation information of Flood LED Light,LED Flood Light Industrial LED Light for Outdoor Square Building Landscape:
1. Check all the parts and accessories of LED flood light;
2. Must cut off the power supply before installation;
3. Make sure the flood light is fixed tightly to the surface of place for installation ;
4. Connect the power line of flood light with power supply, then switch on the power.
5. When the flood light is working, it must be kept vertical downward.
Applications of IP65 LED Flood Light,LED Flood Light Industrial LED Light for Outdoor Square Building Landscape:
1. Advertising board,playground and stadium lighting.
2. Parking lot and airport lighting.
3. Highway and Railway tunnel lighting.
4. Bridge and culvert lighting.
5. Square,garden,and building lighting.
Widely used in factory,gymnasium,billboards,buildings,lawns,landscaping,offices,the site of light project and decorative lighting project etc.
Strict Tests of LED Flood lighting,LED Flood Light Industrial LED Light for Outdoor Square Building Landscape:
Before shipping, all the LED flood lights will be over 12 hours aging tested, inspection department will test 100% products including light up test , power wattage test , high-Voltage test , waterproof test , ground connection test and so on, defective rate is controlled less than 0.1%. Quality is ensured, you can be assured.
Packaging of flood Light LED,LED Flood Light Industrial LED Light for Outdoor Square Building Landscape:
Our individual package maximize protecting the flood lights from transfer damage in transit.
1. Label on backside of each flood light and your required label is available.
2. One piece led flood Light per carton.
3. This is our regular packing of the led flood light, if you need, we can also custom your own color packing and put your logo on it.
Shipping of LED flood lamps : By sea,air,express (DHL,FedEX,UPS,TNT etc.)
Big quantity advised to be shipped by sea.
Samples advised to be shipped by express.
Samll quantity advised to be shipped by air.
